SGG ACTIVE Pro 0.6 is the ultimate high transmittance low-e product, extreme energy efficiency coating glass. It offers the highest thermal insulation ever and therefore allows to get benefit from the biggest energy-savings.

The coating of SGG ACTIVE Pro 0.6 is SGG PLANITHERM 1.16II, which are generally positioned on face 2 and face 5 of a triple glazed unit, with an optimum centre-pane U-value of 0.6 W/m2·K (4-16Ar-4-16Ar-4mm, with 90% argon-filled). Renowned for its extremely neutral appearance, SGG ACTIVE Pro 0.6 very effectively reflects long-wave heat radiation back into a room, thereby minimizing heat loss through a window while also maximizing solar heat gain and natural light transmission.

The high transmission and great thermal performance allow architects and specifiers to utilize large areas of glazing and create bright, and especially is ideal suitable for application in north regions of China.



Enhanced Thermal Insulation

With an optimum centre-pane U-value of 0.6 W/m2·K (4-16Ar-4-16Ar-4mm, with 90% argon-filled), SGG ACTIVE Pro 0.6 can comfortably meet current Building Regulations by improving whole window U-vales for all frame types.

A triple-glazed unit incorporating SGG PLANITHERM1.16 II is more thermally efficient than an ordinary double-glazed unit.

-  Considerable reductions in heating bills

-  Reduces condensation on the inner pane

-  Eliminates cold areas around windows resulting in greater comfort

-  Environmentally friendly solution, given the lower CO2 emissions associated with reduced energy consumption

-  Facilitates compliance with building regulations for a wider range of frame designs










House windows - Day-light for House windows

The high transparent glass or larger sizes of the windows enable a better illumination of your home indoor space, which has a positive impact on your health: Several international scientific studies have shown the healthy effect of natural day-lighting on human-beings.


House windows - Energy Saving For House windows

Installing energy efficient windows with SGG's high performance Low-E or solar control glass can save your energy bills compared to traditional windows and frames.

Our own research has shown that many homeowners are unaware of the performance differences between different types of window glass, instead assuming that all double glazing is equally energy efficient. In reality, there are significant differences in performance with the type of glass used being key.



House windows - Thermal Insulation for House windows

Thermally insulating glass (also known as low-emissivity or low-E glass) usually forms the inner pane of an Insulating Glass Unit (IGU).The glass has a transparent metallic coating that reflects heat from radiators or fires back into the room, rather than allowing it to escape through the windows. At the same time it allows free heat and light from the sun (known as passive solar heat gain) to pass through the glass, warming your home and further contributing to the energy efficiency of your windows.



Passive house - Day-light for Passive house

Day-Light Comfort can be optimized with the following high-performance glass: SGG PLANITHERM, the high transparent glass or larger sizes of the windows enable a better illumination of your home indoor space.



Passive house - Energy Saving for Passive house

A Passive House is a comprehensive system, high performance triple-glazed windows with super-insulation Low-E glass (product like SGG ACTIVE Pro 0.6), limitation of thermal bridging and excellent warm edge spacer bar (such as SWISSPACER®) all make possible extraordinary reductions in energy use and carbon emission. Avoidance of heat gain through shading and window orientation also helps to reduce the cooling system load, which is similarly minimized.


Passive house - Thermal Insulation for Passive house

Windows in Passive house constructions have a U-value of 0.8 W/m2K or less. SGG ACTIVE Pro 0.6 is the most popular and proper choice for the passive house window, because it gives the best thermal performance with Uglass-value of 0.6 W/m2·K with the triple glazing composition, that could do great contribution to make sure the Window u-value ≤ 0.8 W/m2·K.
