RADOME 5G ANTENNAS
Radome Systems for 5G Panels & High-Frequency Antennas
Specification
SHEERGARD® 5G radomes provide protection to high-frequency point-to-point communications systems in any urban, rural or marine environment.
Our radome covers can be fabricated with an array of materials to best suit your application and protect your high frequency antennas or 5G panels. Thin PTFE fabrics can be deployed as part a pre-tensioned frame designed to easily mate with any underlying structure; lightweight sandwich covers can be tuned to any transmitting or receiving frequency and snap-fitted to a mating housing; or lastly, semi-rigid composite laminates can provide the best of both worlds by integrating into subsequent assembly steps to provide an easily automated solution.
All of our high frequency radome systems are proven to provide permanent hydrophobicity over a 20-year life span, prevent the collection of snow, water or ice, and are actively self-cleaning to remove signal blocking debris and maintaining the desired aesthetic. They are suitable for EHF and SHF antennas.
The choice of system will depend on your frequency range, mounting application and environmental needs. All technologies have been modularly designed, and so can be customized and developed to any specific need. Please contact us below for more information.
Our offering for EHF/SHF radomes and 5G panel covers:
| Property | Value |
|---|---|
| Technology | Air-inflated, fabric, laminate, sandwich radomes |
| Frequency | 0.5 - 40 GHz |
| Tensile strength | 1,200 pli |
| 3D fiber density | 3 fibers per square inch |
| Key materials | PTFE, Kevlar, Fiberglass |
| Corrosion resistance | Non-metallic components, stainless steel, anodized aluminum |
| UV exposure | 1,000 hours UVA and UVB |
| Temperature range | -40°F - 160°F |
| Hail resistance | 3" dia. at 58 m/s |
| Environmental protection | MIL-STD-810F |
| # of active systems | +50 sites, 12 countries for our Sheergard® range |
| Real-life experience | +60 years |
| Warranty options | 1 - 5 years |
| Quality management | ISO 9000 |
| Country of origin | United States |
Extreme Environmental Protection
SHEERGARD® PTFE coated fabrics have been analyzed and tested for structural application to all environmental conditions.
Proven Reliability
The materials used for radome fabrication are composites consisting of a woven substrate fabric protected with applied coatings, providing tensile strength and tear resistance.
Complete Vertical Integration
SHEERGARD® incorporates vertical integration of all elements in the composite manufacturing process including yarn twisting
and weaving, polymer coating, casting and lamination.
Unsurpassed RF Performance
The primary function of a radome is to protect the enclosed antenna system while having minimal effect on the transmission of the electromagnetic signal.
